Model Number: LRF4-OCR2B-P-WH
Features
- Passive infrared motion detection with exclusive Lutron XCT Technology
- 3 settings occupancy sensor available: Auto-On / Auto-Off, Auto-On Low-Light / Auto-Off, and Manual-On / Auto-Off
- Auto-On Low-Light feature will turn lights on automatically only if there is less than approximately 10 Lux (1 fc) of ambient light
- Uses Clear Connect technology
- Simple and intuitive adjustments available for Timeout, Auto-On, and Activity settings
- Supports advanced occupancy features, such as dependent occupancy groups and customizable occupied / unoccupied presets in some systems
- Extend coverage by adding on sensors
- Lens illuminates during test mode to verify ideal locations , Easy programming with front accessible test buttons
- 10-year battery life design
- RoHS compliant
Specifications
Regulatory
• Lutron Quality Systems Registered to ISO 9001:2008
• iDA registered (Singapore)
Power / Performance
• Operating voltage: 3 V• Operating current: 14 μA nominal • Requires one CR 123 lithium battery
• 10-year battery life
• Non-volatile memory (saved changes are stored during power loss)
Environment
• Temperature: 32 ˚F to 104 ˚F (0 ˚C to 40 ˚C) • For indoor use only • Relative humidity: less than 90% non-condensing
Warranty
• 5-Year Limited Warranty. For additional Warranty information, please visit www.lutron.com/ TechnicalDocumentLibrary/Sensor_Warranty.pdf
RF Range
- Local load controls must be located within 18 m line-of-sight, or 9 m through walls, of a sensor
Sensor Coverage Test
• Front accessible test button
• Lens illuminates orange in response to motion during test mode and is visible from 60 ft (18 m)
Wireless Communication Test
• Front accessible test button
• Turn associated loads on and off
Timeout Options
• 1 minute
• 5 minutes
• 15 minutes (default setting)
• 30 minutes
